ASI-T-10251248AKLN/D

ASI-T-10251248AKLN/D is a 10.25 inch wide TFT, with a resolution of 1280 x 480, LVDS interface, IPS all view, with wide temperature operation and storage and a high brightness of 1,000 Nits.

TFT Specifications
Size 10.25
Resolution

1280 x 480
Module Size

258.60 x 107.00 x 6.31
Active Area

243.84 x 91.44
Interface LVDS
Touch Panel None
Brightness/Nits Range 1000 & up
Brightness/Nits 1000
PDF

Polarizer Transmissive
Viewing Direction IPS/All-view
